IM-S02-30 CMGT Issue 14
2
FT43, FT44, FT46 and FT47 Ball Float Steam Traps
Safe operation of these products can only be guaranteed if they are properly installed, commissioned,
used and maintained by qualified personnel (see Section 1.11) in compliance with the operating
instructions. General installation and safety instructions for pipeline and plant construction, as
well as the proper use of tools and safety equipment must also be complied with.
1.1 Intended use
Referring to the Installation and Maintenance Instructions, name-plate and Technical Information
Sheet, check that the product is suitable for the intended use/application.
The products listed below comply with the requirements of the EU Pressure Equipment Directive/UK
Pressure Equipment (Safety) Regulations and carry the mark when so required.
The products fall within the following Pressure Equipment Directive categories:
Product
Group 2
Gases
Group 2
Liquids
FT43
DN15 - DN40 SEP SEP
DN50 1 SEP
DN80 - DN100 2 SEP
FT44, FT46 and
FT47
DN15 - DN20 SEP SEP
DN25 - DN50 1 SEP
DN80 - DN100 (FT44 only) 2 SEP
i) The products have been specifically designed for use on steam, air or water/condensate which
are in Group 2 of the above mentioned Pressure Equipment Directive.
ii) Check material suitability, pressure and temperature and their maximum and minimum values.
If the maximum operating limits of the product are lower than those of the system in which it is
being fitted, or if malfunction of the product could result in a dangerous overpressure or
overtemperature occurrence, ensure a safety device is included in the system to prevent such
over-limit situations.
iii) Determine the correct installation situation and direction of fluid flow.
iv) Spirax Sarco products are not intended to withstand external stresses that may be induced by
any system to which they are fitted. It is the responsibility of the installer to consider these
stresses and take adequate precautions to minimise them.
v) Remove protection covers from all connections and protective film from all name-plates, where
appropriate, before installation on steam or other high temperature applications.
1.2 Access
Ensure safe access and if necessary a safe working platform (suitably guarded) before attempting
to work on the product. Arrange suitable lifting gear if required.
1.3 Lighting
Ensure adequate lighting, particularly where detailed or intricate work is required.
1. Safety information
