FT43, FT44, FT46 and FT47 Ball Float Steam Traps
6.1 FT43, FT44, FT46 and FT47 (DN15 to DN50)
Dowel
Steam lock
release assembly
19 + 21
2
2
3
20
Warning
The cover gasket contains a thin stainless steel support ring which may cause physical injury
if not handled and disposed of carefully.
6. Maintenance and spare parts
18 17
Bimetallic air vent assembly
