2.3 Pressure / temperature limits

Body design condition PN16

Maximum receiver operating pressure 0.5 bar g

MFP14 13.8 bar g

Maximum motive inlet pressure

MFP14S 13.8 bar g

(steam)

MFP14SS 10.96 bar g

MFP14 16 bar g @ 120°C

PMA Maximum allowable pressure MFP14S 16 bar g @120°C

MFP14SS 16 bar g @ 93°C

MFP14 300°C @ 12.8 bar g

TMA Maximum allowable temperature MFP14S 300°C @ 10.8 bar g

MFP14SS 300°C @ 9.3 bar g

Minimum allowable temperature 0°C

MFP14 13.8 bar g @ 198°C

PMO Maximum operating pressure MFP14S 13.8 bar g @ 198°C

MFP14SS 10.96 bar g @ 188°C

MFP14 198°C @ 13.8 bar g

TMO Maximum operating temperature MFP14S 198°C @ 13.8 bar g

MFP14SS 188°C @ 10.96 bar g

Minimum operating temperature 0°C

Note: For lower operating temperatures consult Spirax Sarco

Designed for a maximum cold hydraulic test pressure of: 24 bar g
