2.4 Sizes and pipe connections
Single MFP14-PPU
For further information regarding installation, location and commissioning
see Section 3.
Unit size
Pipe
connection
V
(Con out)
W
(Motive)
X
(Overflow)
Y
(Vent)
Z
(Inlet)
DN25
(1")
PN16 DN25 DN15 DN50 PN16 DN80 DN40
ASME 150
1"
ASME 150
½"
ASME 150
2"
ASME 150
3"
ASME 150
1½"
ASME 150
DN40
(1½")
PN16 DN40 DN15 DN50 PN16 DN100 DN40
ASME 150
1½"
ASME 150
½"
ASME 150
2"
ASME 150
4"
ASME 150
1½"
ASME 150
DN50
(2")
PN16 DN50 DN15 DN50 PN16 DN150 DN65
ASME 150
2"
ASME 150
½"
ASME 150
2"
ASME 150
6"
ASME 150
2½"
ASME 150
DN80 x DN50
(3" x 2")
PN16 DN50 DN15 DN50 PN16 DN150 DN65
ASME 150
2"
ASME 150
½"
ASME 150
2"
ASME 150
6"
ASME 150
2½"
ASME 150
Duplex MFP14-PPU
For further information regarding installation, location and commissioning
see Section 4.
Unit size
Pipe
connection
V
(Con out)
W
(Motive)
X
(Overflow)
Y
(Vent)
Z
(Inlet)
DN40
(1½")
PN16 DN40 DN15 DN50 DN150 DN50
ASME 150
1½"
ASME 150
½"
ASME 150
2"
ASME 150
6"
ASME 150
2"
ASME 150
DN50
(2")
PN16 DN50 DN15 DN50 DN200 DN65
ASME 150
2"
ASME 150
½"
ASME 150
2"
ASME 150
8"
ASME 150
2½"
ASME 150
DN80 x DN50
(3" x 2")
PN16 DN50 DN15 DN50 DN200 DN80
ASME 150
2"
ASME 150
½"
ASME 150
2"
ASME 150
8"
ASME 150
3"
ASME 150
Triplex MFP14-PPU
For further information regarding installation, location and commissioning
see Section 5.
Unit size
Pipe
connection
V
(Con out)
W
(Motive)
X
(Overflow)
Y
(Vent)
Z
(Inlet)
DN80 x DN50
(3" x 2")
PN16 DN50 DN25 DN50 DN250 DN80
ASME 150
2"
ASME 150
1"
ASME 150
2"
ASME 150
10"
ASME 150
3"
ASME 150
