IM-P186-03 CH Issue 4
11
Fig. 4
Pressure
adjustment
spring
2
7
Spring housing
hexagon bolts
Bellows assembly
19
11
Valve and seat
assembly
18
4
5
6
12
6
Gasket set
12
6
13
1
15
16
