SAFETY LABELS, UNIT COMPONENTS FEATURES & CONTROLS
WATER INLET
CONNECTOR
PRESSURE GAUGE
TRIGGER
UNIT ON / OFF
SWITCH
HIGH PRESSURE
HOSE
PRESSURE
HIGH / LOW
LANCE HOLDER
HANDLE
PLUG
(SLD10 ONLY)
LANCE
CHEMICAL HOSE
HIGH PRESSURE WATER
OUTLET CONNECTOR
SERIAL LABEL
(REMOVE PANEL TO VIEW)
Always pay attention to the safety instructions provided on each label. Do not alter or remove safety labels
CHEMICAL FLOW
ADJUSTMENT
LANCE HOLDER
