-8-
Universal Mounting (CONT'D)
2. Use the screws to attach the
"L"-Brackets to either end of
the light as pictured to the
right. You may desire to
remove the nylon spacer if
the screw does not securely
fasten to the base.
CAUTION: Take extreme
caution not to over tighten the
screws!!! Over tightening of
the screws can strip the holes
and result in a faulty mount.
or
Remove outermost screws
from bottom of unit.
(Bottom View)
Attach The Suction Cups or Window Adhesive Mounts
1. Remove the two #4 x 1/4" Phillips pan head screws on either end of the bar,
along with the washers and nylon spacers.
3. Then use the appropriate hardware (as shown above) to attach either the
Adhesive Pads or the Suction Cups, depending upon your application.
If using the window adhesive:
•
Be sure to use the tube of cleaner to clean both surfaces.
•
After applying adhesive, please allow a minimum of 2-5 minutes
for the pad to adhere to the window before releasing pressure.
•
Allow 24 hours for the adhesive to fully cure before using.
4. Continue to the BAFFLE ADJUSTMENT section on page 11.
