Data di emissione: Dicembre, 2017 Revisione: 1 Pag. : 34/40
12. SPECIAL MAINTENTANCE
Caution
Before proceeding with any maintenance
operation, it is compulsory to switch off the
machine and unplug it from the mains.
Condenser cleaning
In order to guarantee good cooling system
performance, the condenser must be well
cleaned every month.
How to reach it:
- Switch off the power supply and disconnect
the power cable.
- Remove the side panel protecting the
condenser.
- Clean the condenser fins properly with a soft
brush or a vacuum cleaner (see figure 22).
- reassemble the panel back in place.
!ATTENTION!
Failure to maintain a clean condenser will
cause damage to the unit and consequently
void the warranty.
Fig. 22
