68
No. Description Quantity No. Description Quantity
1 Pedestal 1 53 Moving roller bush 2
2 Column (L+R) 2 Motor front protecting cover 1
3 Computer frame 1 54 Plastic edge-strip 2
4 Incline frame 1 55 Side edge-strip 2
5 Main frame 1 56 Silicone oil tank 2
6 Motor support 1 57 Oil pipe 2
7 Little handle(L+R) 2 58 Tubing bushing 2
8 Silicone Oil 2 59 R-type wire clamp 4
9 Package stator 1 60 End cap 1
10 Running board 1 61
End cap inner decorative
cover
2
11 Running belt 1 62 End cap side decorative cover 2
12 Front roller 1 63 Pedestal Adjusting foot pad 4
13 Rear roller 1 64 Rubber gasket 2
14 Motor Belt 1 65 Moving roller bush 2
15 Gas spring 1 66 Moving roller 2
16 DC motor 1 67 Frame Adjusting foot pad 2
17 Incline motor 1 68 Round cushion pad 8
18 Compression Spring 1 69 Square inner tube plug 5
19 Computer PCB 1 70 Round cushion pad 2
20 Controller(lower controller) 1 71 Plastic spacer 6
21 Grip pulse 2 72 Edge-strip buckle 8
22 Speaker 2 73 Thickening Edge-strip buckle 8
23 MP3 connecting line 1 74 M4 Flat gasket 13
24 Safety lock 1 75 M8 Flat gasket 38
25 Computer top line 1 76 M10 Flat gasket 6
26 Computer bottom line 1 77 M8 Spring washer 6
27 150 single line 2 78 M8 Lock nut 14
28 300 single line 2 79 M5 L-wrench 1
29 150 single ground line 1 80 M6 L-wrench 1
30 Overload protector 1 81 Cross open-end wrench 1
31 Power switch 1 82
Half-round head hexagon so-
cket head cap screw M10*40
1
6. PARTS LIST
