Chapter 2:2
Chapter 2: Installation
Figure 2 – Panel Dimensions for 74, 104, and 147 Amp Elevator Panels
CAT. XXXXXXXX SER. B
Dimensions in mm (in)
Weight 14lbs (6kg)
Figure 3 - Panel Dimensions for 234 Amp Elevator Panels
CAT. XXXXXXXX SER. B
Dimensions in mm (in)
Weight 51lbs (23kg)
This screw is intended for securing: a) a prepared bonding conductor (such as one with crimped-on lug); or
b) a suitable terminal for connection of an unprepared bonding conductor (stripped wire end). This screw
is not intended for direct field wiring connection of an unprepared conductor or equipment grounding
conductor.
see
see
