Chapter 3: Programming
Chapter 3:4
Basic Timing Diagram, No Soft Stop
On
Control Power
Off
Fault Occurs Fault Reset
On
Start Enable
Off
Closed
Fault Contact
(Fault Contactor) Open
Possible Aux Contact Configurations
Closed
Up to Speed
Open
Closed
Normal
Open
Input and Output timing
