SPX FLOW Hankison HPR Series User Manual

2
GENERAL SAFETY INFORMATION
1. PRESSURIZED DEVICES:
This equipment is a pressure containing
device.
• Donotexceedmaximumoperating
pressure as shown on equipment
serial number tag.
• Makesureequipmentisdepressurizedbeforeworking
onordisassemblingitforservice.
2. ELECTRICAL:
This equipment requires electricity to
operate.
• Installequipmentin compliancewith
all applicable electrical codes.
• Standard equipment is supplied with electrical en-
closures not intended for installation in hazardous
environments.
• Disconnectpowersupplytoequipmentwhenperform-
inganyelectricalservicework.
3. BREATHING AIR:
• Airtreatedbythisequipmentmaynot
besuitableforbreathingwithoutfur-
ther purification.
 Refer to applicable standards and
specicationsfortherequirementsfor
breathing quality air.
RECEIVING, MOVING, AND UNPACKING
A. RECEIVING
Thisshipmenthasbeenthoroughlychecked,packedand
inspectedbeforeleavingourplant.Itwasreceivedingood
conditionbythecarrierandwassoacknowledged.
CheckforVisibleLossorDamage.Ifthisshipmentshows
evidenceoflossordamageattimeofdeliverytoyou,in-
sistthatanotationofthislossordamagebemadeonthe
delivery receipt by the carrier’s agent.
B. UNPACKING
Checkforconcealedlossor damage. Whena shipment
has been delivered to you in apparent good order, but
concealed damage is found upon unpacking, notify the
carrier immediately and insist on his agent inspecting the
shipment. Concealed damage claims are not our respon-
sibilityasourtermsareF.O.B.pointofshipment.
C. MOVING
Inmovingortransportingdryer,donottipdryerontoits
side.
D. STORAGE
IMPORTANT:  Do not store dryer in temperatures above
130°F (54.4°C).
Contents
GENERALSAFETYINFORMATION ..................................... 2
RECEIVING,MOVING,ANDUNPACKING ........................... 2
INSTALLATION ................................................................... 3
INSTRUMENTATION .......................................................... 4
DRAINVALVES ................................................................. 4
START-UP/OPERATION ...................................................... 4
SHUTDOWN ...................................................................... 4
MAINTENANCE ................................................................. 5
FIELDSERVICEGUIDE ....................................................... 6
ENGINEERINGDATA ......................................................... 7
ELECTRICALSCHEMATICS ................................................. 8
AIRANDREFRIGERANTFLOWSCHEMATICS ..................... 9
REPLACEMENTPARTS ...................................................... 10
WARRANTY ...................................................................... 11
