ENGINEERING DATA
MODEL HPR25 HPR35 HPR50
SPECIFICATIONS
Rated Capacity
a
-(scfm) 25 35 50
Inlet/OutletConnections-(inches) 3/4 3/4 3/4
Dimensions
Height-(inches) 22.2 22.2 22.2
Length-(inches) 15.5 15.5 19.7
Width-(inches) 14.5 14.5 19.7
PowerSupply-(V/Ph/Hz) 115/1/60 115/1/60 115/1/60
RefrigerantCompressorRating-(hp) 1/4 1/4 1/3
InputPower-(kW) 0.47 0.47 0.63
RefrigerantType
b
R-134a R-134a R-134a
a
Rating conditionsare100°Finlettemperature,100psiginletpressure,100%inletrelativehumidity,100°Fambienttemperature@60Hz.PerCAGIADF-100.
b
Refertodryerdataplateforrefrigerantcharge.
MODEL HPR25, HPR35, HPR50
MINIMUM - MAXIMUM OPERATING CONDITIONS
Min.-Max.InletAirPressure(compressedairatinlettodryer) 30 - 250 psig
Min.-Max.InletAirTemperature(compressedairatinlettodryer) 40°F - 120°F
Min.-Max.AmbientTemperature 40°F - 110°F
NOTE:Continuousoperationintheabovemaximumandminimumoperationconditionsisnotallowable.
