ACMM16WC0002 REV0.2 INSTRUCTION MANUAL DELAIR® ETSILINE COMMPACT
45
ACMM16WC0002 INSTRUCTION MANUAL DELAIR® ETSILINE COMMPACT
CHAPTER 6 PAGE 45
Browser
menu
Parameter Default
Setting
Design Limits / remarks
Installer
Pressure low
limit
20
mBarg
Lower limit (compressor on)
When system pressure drops below this setting, supply valve Y3 and,
dependent of other conditions, compressor is switched ON
Pressure high
limit
30
mBarg
High limit (compressor off)
When system pressure exceeds this setting, supply valve Y3 and, depen-
dent of other conditions, compressor is switched OFF
During heating cycle compressor is always ON and only feed valve Y3 is
switched OFF.
Ensure this pressure is always higher than the Press.low limit.
Reset operation
time
Off Reset the running hours of the unit
Reset runtime
compr. 1
Off Resets the running hours of compressor 1
Reset runtime
compr. 2
Off Resets the running hours of compressor 2
Pressure sen-
sor range
5 PSI Pressure sensor range (1-150PSI)
Adjust P-sensor 0 mbarg Pressure sensor correction (-200 - +200mbar)
With this function an offset to the actual reading can be set.
This value will be added/ subtracted from the actual pressure measure-
ment.
Enable remote
sense
Off *
To enable remote sensing (On – Off)
Enabling this only makes sense if this option is installed. Remote sensing
is the option to measure the pressure downstream the air dryer (in sys-
tem) instead of at the discharge of the air dryer. * In Etsiline Commpact
the Remote Sense is manually operated via valve RS located in the front
panel, not via valve Y4.
Remote sense
enabled
Disable
button
No function
PSI reading Off PSI Read-out (On - Off)
Switch between PSI (On) and mbar read-out (Off).
Functions assignments settings always in mbar’s
Compressor
runtime alarm
60 min-
utes
Excessive run time compressor (0 – 60 min.)
When the compressor operates beyond adjusted time limit, an excessive
air consumption alarm will be generated.
Alarm is only activated during “COOL1” or “COOL2” period and not func-
tion during the “HEATER1” or “HEATER2” regeneration period.
Display would indicate “PUMP AL.” if this setting is exceeded
Test modus
active
Off Test mode (On – Off)
This function puts the unit in test mode. All I/O are frozen in the current
state. I/O can be changed with below test functions.
Analog sensor
input
Disabled Selects whether an analog sensor is installed (Off-On)
Switches the relative humidity or dew point sensor ON or OFF.
Only applicable for installations with RH-sensor
Sensor type Digital Analog / Digital
Sensor units Humidity Units for humidity (RH – DP)
Switches between a RH-sensor and a DP-sensor
Humidity alarm
(optional)
7% Humidity alarm setting (5-100%)
When system humidity exceeds this setting, an alarm “HIGH RH” will be
displayed after presetted time-delay. Alarm setting only possible with a
RH-sensor and will not alarm in case a DP-sensor is installed.
