ACMM16WC0002 REV0.2 INSTRUCTION MANUAL DELAIR® ETSILINE COMMPACT
65
ACMM16WC0002 INSTRUCTION MANUAL DELAIR® ETSILINE COMMPACT
CHAPTER 8 PAGE 65
8. Spare parts
POS DESCRIPTION PARTNR QNTY REMARK
1 Humidity indicator 0148193 1
2 Gasket for humidity indicator
3 Switch ON/OFF 0281534 1
4A Alarm connector elbow (solder) 0268924 1
4B Alarm connector straight (screw) 0268910 1 Optional
5 Voltage Adaptor 60-264VAC/48VDC 0281544 1 Not on drawing
7 Connector power supply 0281532 1
8 Printed circuit board+LCD display 0266401 1
9 Airpump 0266403 2
10 Adsorber with heater 0266410 2
11A Status display LCD 0266392 1
11B Status display OLED 0266411 1 Optional
13 Mouting bracket 0281502 2
