CAUTION! DO NOT TOUCH THE GROUND CABLE WHILE DETECTOR
IS OPERATING.
OPTIONAL: BRUSH ADAPTER KIT. The Model 780 Kit comes with a
brush adapter kit for use in connecting flat brush / neoprene electrodes, half-circle
electrodes and full-circle electrodes.
STEP 3. CONNECTING THE CLIP \ SHOULDER STRAP. First attach the
strap clip to the black handle by placing the tab portion of the strap clip into the
top groove on the back side of the handle that faces the unit display. Then push
up on the bottom of the strap clip in the direction of the opposite side of the black
handle until the strap clip snaps into place around the black handle. Next attach
the shoulder strap to the front handle clip and the pin on top of the rear handle.
The front clip can slide to the left or right on the handle to allow hand placement
while using the detector.
STEP 4. BATTERY. The battery will only install one way (from the front side).
It is keyed to prevent insertion in an incorrect fashion. One end of the battery
is flat and the other has a step. The flat end goes towards the rear of the unit.
Push the battery on until it snaps in place (the spring will be almost completely
compressed when properly installed). To remove the battery, press the orange
release on the bottom left side of the unit. Newer batteries can be a bit resistant
when trying to remove the battery because of the newness of the battery and
the tight fit on the slide path; if so give a gentle tap with your palm on the battery
in the direction of removal.
STEP 5. CONNECTING THE GROUND CABLE. The ground cable plugs
into the bottom side of the rear handle. It uses a quarter turn fastener, so insert
the cable as far as possible and rotate it at least a quarter clockwise turn until it
locks into place. The kit includes a quick connect grounding clamp that allows
the option to take the clamp on or off the ground wire for different grounding
methods. Earlier kit versions did not include a grounding clamp and you can order
one from SPY if you would like the ability to add one to your ground cable.
PROPER GROUNDING. Make sure the ground cable is uncoiled and
extended.
