Assembly compatibility
and operational safety
Sizing
The SQlab grips are designed for mount-
ing on standard bicycle handlebars, with a
grip clamping diameter of 22.2 mm.
The SQlab grips , ,  and OX are
available in 2 or 3 dierent sizes, which
can be determined by your nger length.
The sizes dier in diameter, length and
shape.
The grip width is the measurement from
the tip of the middle nger to the crook of
the thumb. This is precisely what you grasp
the grip with.
You can easily download the grip template
shown in the gure in the "Ergonomics"
section of our website under "Grip width
determination".
Component replacement of the SQlab screw-clamped grips is possible on fast pedelecs known as S-Pedelec that are classied as mo-
tor vehicles and subject to EU Directive 2002/24/E6 or EU Regulation No. 168/2013 is possible based on the Guidelines "Component
Replacement on S-Pedelecs - Fast E-Bikes / Pedelecs with pedalling assistance up to 45 km/h" by the Federal Guild Association for the
German Two-Wheel Mechanical crasmanship (BIV), TÜV Rheinland, velotech.de, service and bicycle association (VSF), Zedler Institute
and the two-wheel industry association (ZIV), provided that the vehicle width is not changed.
Warning
The manufacturing tolerances of the
grips and the handlebars can lead
to the grips not being suciently se-
cured against twisting and becoming
pulled o. In case of problems, please
contact your SQlab dealer.
Warning
Always follow the instructions and
warnings given in the assembly and
operating instructions for your han-
dlebars.
Replacing SQlab grips on Pedelec45
large
medium
small
1
9
5
13
2
10
6
14
16
3
11
7
15
17
4
12
8
large medium small
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
SQlab Griweitenbestimmung
Grip Size Template
So funktionierts ...
1. Hand auf die Abbildung legen und den Mittelnger
in Höhe des Pfeiles positionieren.
2. Daumen etwas abspreizen.
3. Die Daumenbeuge mit einem Sti markieren.
4. Größe ablesen und Gri auswählen.
5. Für das MTB empfehlen wir eher den kleineren Gri
zu wählen.
How it works ...
1. Place your hand on the image and position the
middle nger at the arrow.
2. Stretch the thumb to the side.
3. Mark the bottom most point between the thumb
and index nger.
4. Note the size and select the grip.
5. For MTB we recommend choosing one size smaller.
has been jointly released by the associations Zweirad-Industrie-Verband (ZIV) and Verbund Service und Fahrrad (VSF) in cooperation with
the Zedler-Institut and the Bundesinnungsband Fahrrad (BIV).
The guideline clearly regulates which bicycle dealers and repairers are allowed to replace parts on these vehicles and for which parts
they require approval from vehicle manufacturers or system suppliers. As such, it can be regarded as a recommended course of action.
Replacing the SQlab grips on the Pedelec25 is based on the recommendation "Guidelines for the replacement of components in CE-
marked e-bikes/pedelecs with pedal assistance up to 25 km/h" (https://www.zedler.de/les/kunde/prueechnik/PDF/Leitfaden_Bau-
teiletausch_Stand_14-06-2016-2.pdf) by the associations Zweirad-Industrie-Verband (ZIV) and Verbund Service and Bicycle (VSF) in
cooperation with the Zedler-Institut and the Bundesinnungsverband Fahrrad (BIV).
