SQlab | SPORTS ERGONOMICS | 702, 710, 711 AND 7OX | EDITION US 2019-01 | Page 8
Assembly
Tools
To mount the grips, you will need a clean cloth, cleaning products (brake cleaner), a suitable Allen key for clamping the grips, brake and
shi levers and a torque wrench.
Product Allen key size Nut tightening torque (Nm)
SQlab  4 5
SQlab  4 5
SQlab  3 3
SQlab OX 3 3
Warning
Incorrectly mounted components pose a signicant risk.
• You must read and understand the instructions and notes before beginning assem-
bly.
• If you have questions about mounting these components, contact your SQlab deal-
er or have your grips tted by an experienced bicycle mechanic.
The grips are labelled on the underside with the size and "L" (le) or "R" (right).
SQlab OX – size and side specication
SQlab – size and side specication
SQlab  – size and side specication
SQlab – size and side specication
