SSD SHOETESTER II - Items Included with the Device

Items Included With the Device
Confirm that the following items are included with the device before using it for the first time.
 Instruction manual/warranty x 1 (this document)
 Main Device
 Measurement stand Wall mounting rack
Power
switch
Touch button
Self-check
button
O
p
eration settin
g
Power input connector
Insert the dedicated AC adapter here
Earth terminal
Result output terminal
Insert the
result
signal cable here (optional)
Measurement signal connector
Insert the dedicated measurement signal cable
here
RS232C
Measurement result display area
Minimum setting
switch
Minimum setting
switch
