SST 1200 - Page 123

MATL:
FILE:
DR BY:
TITLE:
SST INTERNATIONAL
DIR:
CHK.BY:
PART #
FINISH:
SCALE:
SHT
OF
DATE:
NEXT ASSY:
REF:
CALIFORNIA USA (562)803-3361
TOLERANCES UNLESS SPECIFIED
DIMENSIONS ARE IN INCHES
.X .030
.XX .010
.XXX .003
ANG. 30'
- MACHINE SURFACES FLAT
WITHIN .002 INCH/INCH.
- OTHER SURFACES FLAT
WITHIN .005 INCH/INCH.
- TIR WITHIN 1/2 SUM OF
DIAMETER TOLERANCE
.005 MINIMUM
DNR
.XXXX .0010
AB
THIS DOCUMENT CONTAINS MATERIAL PROPRIETARY TO SST INTERNATIONAL.
2X THRU
.2508
.2503
4.0000
.500
2X 2.000
.13
2.00
.20 FLAT BOTTOM
.100 X 60
.041
.040
NOTED
ASSY, TARGET PLATE
TEMIC
13 AUG 07
1.000
& NOTED
11759-100
1 1
ITEM # PART # QTY DESCRIPTION
1 500-172-4 2 DOWEL, BULLET-NOSE
2 11759-01 1 TARGET PLATE
REV DESCRIPTION ECO # DATE
NC INITIAL RELEASE 3358 13 AUG 07
11759-100_TARGET_PLT_ASSY
/TEMIC/SO11759
11759-01 TARGET PLATE
MAKE FROM 35228
SCALE 0.750
1
2
ENGRAVE MO/YR SST 11759-01
AS SHOWN
