SST 1200 - Fuse Table; Fuse Identification and Function

FUSE TABLE 110V, 220V
Symbol Description Function Part Number
(110V )
1FU 25A, 250V, BLF-25 Heater Circuit 31741-25
6FU 3A, 240V, 3AG-2 Control Circuit 12-1830
(220V)
1FU 15A, 250V, BLF-15 Heater Circuit 31741-15
2FU 15A, 250V, BLF-15 Heater Circuit 31741-15
5FU 1.5A, 240V, 3AG-1.5 Cont. Trans. Primary 12-1820
6FU 3A, 240V, 3AG-2 Cont. Trans. Secondary 12-1830
(110V, 220V)
3FU 25A, 240V, KAX-25 SSR Protection 35170
4FU 1.5A, 240V, 3AG-2 Control Circuit 12-1820
7FU .5A, 240V, 3AG-.5 GAS 1A Solenoid 12-1810
8FU .5A, 240V, 3AG-.5 GAS 1B Solenoid 12-1810
9FU .5A, 240V, 3AG-.5 GAS 2A Solenoid 12-1810
10FU .5A, 240V, 3AG-.5 GAS 2B Solenoid 12-1810
11FU .5A, 240V, 3AG-.5 Vacuum Solenoid 12-1810
12FU .5A, 240V, 3AG-.5 Exhaust Solenoid 12-1810
13FU .5A, 240V, 3AG-.5 Process Controller 12-1810
14FU .5A, 240V, 3AG-.5 DC Power Supply Line 12-1810
15FU 1.5A, 240V, 3AG-1 DC Power Supply Load 12-1820
16FU .5A, 240V, 3AG-.5 Master PLC 12-1810
17FU .5A, 240V, 3AG-.5 Lid Control PLC 12-1810
