Pin Name Pin Number Signal or Label Comment

P12 E1 VLX -

P13 F2 VSSIO_SD -

P14 U11 VCAP1 -

P15 D17 VCAP2 -

R1 A7 VCAP3 -

R2 N8 VDDIO1 -

R3 M5 VDDIO2 -

R4 U12 VDDIO33_LDO1 -

R5 C17 VDDIO33_LDO2 -

R6 A6 VDDIO33_LDO3 -

R7 G17 VDD50_USB -

R8 F17 VDD_USB33 -

- L1 VDDA -

- M1 VREF+ -

- B1 VBAT -

- A1 VSS -

- C10 VSS -

- C13 VSS -

- C16 VSS -

- G16 VSS -

- J3 VSS -

- N16 VSS -

- U17 VSS -

- T12 VSS -

- R8 VSS -

- L9 VSS -

- L11 VSS -

- K10 VSS -

- K11 VSS -

- A17 VSS -

- L10 VSS -

- B6 VSS -

- B2 VSS -

- R2 VSS -

- G7 VSS -

- G8 VSS -

- G9 VSS -

- G10 VSS -

- G11 VSS -

- H7 VSS -

UM2488

STM32H745I-DISCO and STM32H750B-DK I/O assignment

UM2488 - Rev 4

page 27/55
