STA-RITE DYNA-GLAS - Page 15

15
MPEA6F-148L
MPFA6F-147L MPEA6G-155L
MPFA6D-176L MPEA6E-147L MPRA6F-148L MPRA6G-155L
MPEA6D-146L MPFA6E-146L MPRA6F-148LC MPR6G-155LC MPEAA6G-168L
MPRA6D-146L MPRA6E-147L MPRA6YF-174L MPEA6YG-175L MPEAA6YG-168L
Key Part MPRA6D-146LC MPRA6E-147LC MPRA6YF-174LS MPEA6YG-175LS MPEAA6YG-168LS
No. Description Qty. 3/4 HP 1 HP 1-1/2 HP 2 HP 2-1/2 HP
2 Screw #10-32x1/2" 1 U30-692SS U30-692SS U30-692SS U30-692SS U30-692SS
3 Bonding Lug 1 U17-568 U17-568 U17-568 U17-568 U17-568
4 Slinger (MPFA, MPRA Series) 1 17351-0009 17351-0009 17351-0009 17351-0009 17351-0009
4 Slinger (MPEA Series) 1 C69-24 C69-24 C69-24 C69-24 C69-24
5 Seal Plate 1 C3-184P C3-184P C3-184P C3-184P C3-184P
6 Seal Plate Cord Ring 1 U9-373 U9-373 U9-373 U9-373 U9-373
7 Shaft Seal 1 37400-0027 37400-0027 37400-0027 37400-0027 37400-0027
8 Impeller* 1 C105-236P C105-236PB C105-236PC C105-236PDA C105-236PEA
8 Impeller (MPRA6Y, MPEA6Y
and MPEAA6Y only) 1 – – C105-236PF C105-236PGAB C105-236PEA
8 Impeller (MPFA6D, MPFA6E, MPFA6F only) 1 C105-236PJ C105-236P C105-236PB – –
8A Gasket 1 – – – 33455-1047 33455-1047
8B Impeller Lock Screw 1 – – – 37337-6080 37337-6080
9 Diffuser 1 C1-270PB C1-270PC C1-270P C1-270P C1-270P
10 Diffuser “O” Ring 1 U9-374 U9-374 U9-374 U9-374 U9-374
11 Tank and Trap Body (Only) 1 C76-58P C76-58P C76-58P C76-58P C76-58P
12 Trap Cover 1 C3-185P C3-185P C3-185P C3-185P C3-185P
13 Trap Cover “O” Ring 1 U9-375 U9-375 U9-375 U9-375 U9-375
14 Trap Basket 1 C8-58P C8-58P C8-58P C8-58P C8-58P
15A Drain Plug 2 U178-920P U178-920P U178-920P U178-920P U178-920P
15B Mounting Screw 5/16-14x5/8" 2 U30-919SS U30-919SS U30-919SS U30-919SS U30-919SS
16 Base - Plastic 1 C4-77P C4-77P C4-77P C4-77P C4-77P
• Base - Steel (LS Suffix) 1 – – 17303-0113 17303-0113 17303-0113
17 Motor Pad - for Plastic Base 1 C35-45 C35-45 C35-45 C35-45 C35-45
17 Motor Pad - for Steel Base (LS Suffix) 1 – – C35-5 C35-5 C35-5
18 Screw #8-32x7/8" Rd. Hd. 7 U30-542SS U30-542SS U30-542SS U30-542SS U30-542SS
19 Lock Washer #8 Ext. Tooth 7 U43-21SS U43-21SS U43-21SS U43-21SS U43-21SS
20 Flat Washer 3/8" 6 U43-62SS U43-62SS U43-62SS U43-62SS U43-62SS
21 Lock Washer 3/8" 6 U43-12SS U43-12SS U43-12SS U43-12SS U43-12SS
22 Nut 3/8-16 Hex 6 U36-38SS U36-38SS U36-38SS U36-38SS U36-38SS
23 Cap Screws 3/8-16x1-1/4" Hex. (LS Suffix) 2 – – U30-75SS U30-75SS U30-75SS
• Lock Washer 3/8” (LS Suffix) 2 – – U43-12SS U43-12SS U43-12SS
24 Cap Screws 3/8-16x1" Hex. * 4 U30-74SS U30-74SS U30-74SS U30-74SS U30-74SS
• Nameplate 1 32155-4071 32155-4071 32155-4071 32155-4071 32155-4071
• Tag, “CAUTION This pump equipped with 1 61002-0002 61002-0002 61002-0002 61002-0002 61002-0002
mechanical shaft seal…”
• Voltage Sticker 1 U27-153 U27-153 U27-153 U27-68 U27-68
• Decal “Overtight trap lid…” 1 U27-644 U27-644 U27-644 U27-644 U27-644
• Tag, “WARNING/CAUTION/Instructions...” 1 C63-12 C63-12 C63-12 C63-12 C63-12
REPAIR PARTS LIST
DYNA-GLAS™ & DYNA-MAX™ POOL PUMP
3/4 through 2-1/2 HP Models Single Speed and Two Speed
• Not illustrated.
* Models with “LS” suffix use 2 only.
