Stack st8130 series User Manual

&KDSWHU  *HWWLQJ 6WDUWHG 67$&. 67 6HULHV 5RDG &DU 'LVSOD\ 6\VWHPV
Wiring Harness
(DFK RI WKH ZLUHV LQ WKH KDUQHVV LV ODEHOOHG
Labels on Short Cables Connection To
S1 to S4 Switches 1 to 4
WS Wheel speed input (ST492 or ST670)
SL Gear shift warning light
AL Alarm warning light
NET Data logging expansion pack
LAP Optional in-car lap timing sensor (Std on ST8130M)
Labels on Long Cables Connection To
A Air temperature sensor (optional on ST8130 variant)
Fuel pressure sensor (Std on ST8130P/M variants)
ES Engine speed (RPM)
OT Oil temperature sensor
WT Water temperature sensor
OP Oil pressure sensor
F Fuel level sensor
B + 12v Supply (Battery)
B - Battery negative (Chassis)
