67$&. 67 6HULHV 5RDG &DU 'LVSOD\ 6\VWHPV ,QGH[
configuration, 27
Fuel Tank Sender calibration, 21
Fuel tank sender Installation, 45
Fuel warning light, 21
Gate RPM, 21
Gate value, 14
delay, 13
Gate value, 13, 16
Gear shift RPM, 21
Gear shift warning light, 18
wiring label, 6
High oil temperature alarm, 21
High water temperature alarm, 21
Ice warning. See Air temperature
Ignition connection, 36
Infra-red beacon. See Beacon
Installing the Stack ST8130, 32
Internal Battery Low message, 15
Labels on wiring, 6
Lamps. See Warning lights
Lap number
display, 11, 12
Lap time, 18
display, 11, 12
recording manually, 12, 18
resetting, 18, 34
Lap timing sensor
installation, 46
wiring label, 6
Lights. See Warning lights
LOW FUEL P, 21
MSS connector, 44
Odometer
display, 9
Oil pressure
alarm, 16, 21
display, 9, 10
Oil pressure sensor
wiring label, 6
Oil temperature
alarm, 16, 21
display, 9, 10
Oil temperature sensor
installation, 40
wiring label, 6
Operating the system, 8
Peak values, 13
displaying, 14, 34
resetting, 14, 34
Peak Values
memory, 15
Performance parameters, 1
Points connection, 37
power supply, 7
Power supply, 6
Pressure sensors, 38
Pulse amplifier
adjustment, 44
connection, 44
installation, 42
specifications, 45
Redisplaying last alarm, 17
Resetting peak values, 14
Resistor connection to coil, 37
5HWXUQHG JRRGV SURFHGXUH, 68
RPM Gate Value. See Gate Value
Shift light. See Gear shift warning light
Shift RPM. See Gear shift RPM
Showing the last alarm, 17
Speed sensor .
See Pulse amplifier or
See Wheel speed sensor
Speedometer, 7
change from MPH to km/h, 34
display, 9
ST492. See Pulse amplifier
ST765. See Air temperature sensor
ST8130 std components, 4
ST8130 optional components, 5
Stack distributors worldwide, iv
Switches
functions - normal operation, 34
installation, 34
operation - configuration, 20
summary of functions, 66
wiring labels, 6
Switching the system on, 8
Tachometer, 5
8VHUV *XLGH
