Page ST215C User Handbook
32
Characteristics
This instrument complies with
Council Directive 89/336/EC
(EMC) & Council Directive
2006/95/EC (safety)
Time
Start delay range: 00:00 to 99hr 59min
Soak time range: 00:00 to 99hr 59min
Resolution: 1 min
Temperature setting
Range: 0 to 1400ºC (R/S) 0 to 1200°C (K/N)
Resolution: 1ºC
Control Accuracy
P.I.D. Control
Reading accuracy: ±0.25% FSD ±1 digit
Power supply
Voltage range: 90 - 264VAC
Frequency: 50/60Hz
Power: Controller 4VA (max)
Switched outputs 125VA
Fuse: 3.15A slow-blow HRC
20mm x 5mm ceramic
Control Relays (2 or 3)
Contact type: SPST NO
Switched Line voltage O/P @500mA max
(for contactor driving)
Thermocouple
R,S,K & N type.
Lead & Connector
2m or 3m flexible grey polyurethane lead
Fitted with either Han7D, Han12Q, Han 15D
or CPC14 connector
Electrical Temperature
Ramp rate: 1 to 999°/hour or FULL
Ramps can be heating or cooling
Ramps
Operating temperature range: -10°C to +55°C
Storage temperature range: -10ºC to +55ºC
Environmental
Enclosure
Material: ABS flame retardant UL 94V-0
Sealing: IP51
Size: 80/68mm(W), 165mm(L), 28mm(D)
Colour: Black/Dark Grey
(RAL9011/RAL7012)
Error Handling
Thermocouple failure detection
Thermocouple reversal detection
Heater failure detection
Kiln over-temperature detection
Room over-temperature detection
Lock-up on error facility
Firing run time hours limiter
User program check
Alarm buzzer
Keyboard lock facility & indication
Kiln heating indicator
Program running indicator
Energy used display
Other
Council Directives 2002/96/EC & 2003/108/EC
The crossed out bin symbol, placed on
this product, reminds you of the need to
dispose of the product properly at the
end of its life. Electrical & Electronic
Equipment should never be disposed of
with general waste but must be sepa-
rately collected for proper treatment. In this
way you will assist in the recovery, recycling &
reuse of many of the materials used in this
product.
Weight
Instrument + cable + wall bracket: 0.50kg (max)
Packaging
Packaged size: 248 x 185 x 58mm
Packaged weight: 0.570kg (max)
Material: ABS flame retardant UL 94V-0
Colour: Black RAL9011
Fixing slot centres (vertical): 70mm
Fixing slot size: 8mm x 4mm
Wall Bracket
