S6
INSTRUCTIONS
PRECISION REV COUNTER
EN
1.1 Accessories
1 Instrument x 1
2 Power wire x 1
3 RPM wire (type A) x 1
4 RPM wire (type B) x 1
5 Sensor wire x 2
6 TH-01_PT1/8 water
temp. sensor x 2
7 Connecting clip x 2
8 Velcro x 1
9 Battery x 1
Please contact your local distributor if the items you have
received are dierent from the ones listed above.
1.2 Optional Accessories
1 Oil temp. sensor adapter
2 Water temp. sensor adapter
3 Extension cable
4 Oxygen sensor
5 Welding sleeve
1
2
3
4
5
These parts are not included
in the delivery but can be
purchased separately. For
further information, please contact your local
distributor.
NOTE
NOTE
16
1
2
3
4
6
5
7
9
8
