4.5 Connecting electric trolley
Plug connection cable into chain hoist and secure.
Fig. 20
Fig. 21
4.6 Mounting guide rollers
Fig. 22
KFN / KFK 10/ 32: B ≥260
KFN / KFK 63 B: >300
4.7 Mounting support rollers
Fig. 23
The support wheel (a) must be in contact with the runway when mounted.
