This chart is provided to help identify the fasteners used in the assembly process. Place the washers or
the ends of the bolts or screws on the circles to check for the correct diameter. Use the small scale to
check the length of the bolts and screws.
NOTICE: The length of all bolts and screws, except those with flat
heads, is measured from below the head to the end of the bolt
or screw. Flat head bolts and screws are measured from the
top of the head to the end of the bolt or screw.
After unpacking the unit, open the hardware bag and make sure that you have all the following
fasteners. Some fasteners may be already attached to the parts.
MILLIMETERS
0 10 20 30 40 50 60 70 80 90
100
110
120
130 140
150
0 1/2
1 1/2
2 1/2
3 1/2
4 1/2
5 1/2
6
6 8
10
12
3/16"
1/4"
5/16" 3/8" 1/2"
HARDWARE IDENTIFICATION CHART
Part No. and Description Qty
49 Carriage Bolt (M8 x 1.25 x 65mm) 4
45 Bolt, Button Head (M8 x 1.25 x 20mm) 6
50 Acorn Nut (M8 x 1.25) 4
59 Washer (M8) 3
46 Arc Washer (M8) 10
63 Screw, Round Head (M5 x 0.8 x 12mm) 4
67 Lock Washer (M8) 10
60 Nylock Nut (M8 x 1.25) 3
53 Screw, Washer Head (M5 x 0.8 x 12mm) 2
To Next Page
