5
Part No. and Description Qty
HARDWARE IDENTIFICATION CHAT
Place washers, the end of bolts or screws on the circles to check for the
correct size. Use the small scale to check the sizes of bolts and screws.
This chart is provided to help identify the hardware used in the assembly process.
After unpacking the unit, open the hardware bag and make sure that you have the following items:
length
length
mm.
in.
INCHES
MILLIMETERS
11/2021/2 31/2 41/2 51/2 61/2
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150
6 8 10 12
3/16" 5/16" 1/2"3/8"1/4"
NOTICE: The length of all kinds of screws and bolts are not included
themselves head, except the flat head screws and bolts.
42 Nylock Nut (M6 x 1) 2
38 Bolt, Round Head (M6 x 1 x 10mm) 2
40 Bolt, Hex Head (M6 x 1 x 47mm) 2
44 Larger Washer (M6) 2
45 Washer (M6) 4
1. Some of the hardware items listed may be attached to other parts.
2. Bolt length is measured from the bottom of the bolt head to the end of the bolt.
NOTE:
