Stamina inLine Traction Control System - Page 11

ASSEMBLY INSTRUCTIONS
STEP 9
Refer to the illustration below. Position the BELT(25) with its two ends to the outside. Install the
BELT(25) by attaching the TRIANGLE HOOKS(19) to the MAIN FRAME(14) with BUTTON HEAD
BOLTS(M8x1.25x15mm)(27).
11
End of belt
End of belt
