Stamina inLine Traction Control System - Arm Pad Adjustment; Cushion Adjustment

13
OPERATIONAL INSTRUCTIONS
CUSHION(6) ADJUSTMENT
The position of the CUSHION(6) is adjustable. Place the
CUSHION(6) at the position which is most comfortable
for supporting your chest when stretching on the inLine®
Traction Control System.
Adjust the CUSHION(6) by loosening, but not removing,
the LOCKING KNOBS(9) and sliding the CUSHION(6) to
desired position. Tighten the LOCKING KNOBS(9) to lock
the CUSHION(6) securely.
ARM PAD(20) ADJUSTMENT
The width between the two ARM PADS(20) must be
adjusted properly to fit the width of your upper body. The
back of your upper arms should rest on the ARM PADS(20)
during use.
To adjust, remove the ADJUSTMENT KNOBS(7) and slid
the LEFT and RIGHT ARM TUBES(3, 4) to the desired
position. Insert the pin of the ADJUSTMENT KNOBS(7)
into one of the adjustment holes in the LEFT and RIGHT
ARM PAD TUBES(3, 4) and tighten securely. Use the same
adjustment hole position on both sides.
