Stamina Seated Inversion Therapy System - Assembly: Back Frame and Seat; Steps 6-8: Back Frame and Seat Attachment

ASSEMBLY INSTRUCTIONS
STEP 6
Insert the BACK FRAME(9) into the BACK PIVOT FRAME(8) and secure BUTTON HEAD BOLTS
(M8x1.25x15mm)(46).
STEP 7
Refer to the Bottom View of the illustration below. Align the hook and loop material on the HINGE WEAR
COVER(34) and the SEAT(32), then press them to attach together.
STEP 8
Attach the SEAT(32) to the SEAT FRAME(6) with ROUND HEAD BOLTS(M6x1x15mm)(43).
9
Bottom View
hook and
loop material
