STAND STEADY TRFSEL63BLBL - Installing the Side Brackets

7 8
Installing the Side Brackets
E
S-A
S-F
• Attach the side bracket to the end of the lifting column with
2 screws using the Allen wrench as shown.
• Repeat the same process to assemble the other side bracket.
E
S-A
S-F
• Attach one end of the crossbar and crossbar
spacer to the lifting column with 2 screws
using the Allen wrench as shown.
• Attach the other end of the crossbar to the
lifting column with 2 screws using the
Allen wrench .
S-F
S-A
D
C
Note: Maintain the lifting columns in a FACE DOWN
position during installation. This will aid in the remaining
assembly steps.
B
S-A
S-F
A
S-F
S-A
B
C
D
A
