STAND STEADY TRFSEL63BLBL - Assembling the Sync Rod

9 10
Assembling the Sync Rod
F
• Turn the right knob counterclockwise as shown to loosen the sync rod .
• Attach the end of the sync rod as shown to the motor spindle in red line
position and turn the right knob clockwise to tighten the connection.
3
2
F
2
• Turn the left knob clockwise as shown to loosen the sync rod.
• Insert the other end of the sync rod into the column as shown.
knob
1
knob
1
