Sync Mode
Introduction
The sync mode setting controls how the flashing of two or more lamps is synchronized. There are two
versions of sync mode: Simultaneous and Alternate.
Simultaneous means that the lamps are in sync, that is they come on and go off at the
same time.
Alternate means that the lamps are out of sync.
The factory setting of sync mode.
When in configuration mode, the number of bright flashes per flash sequence show the current sync
mode setting, see table.
Bright flashes
per flash sequence
Sync mode
1 Simultaneous
2 Alternate
Setting the Sync Mode
WARNING
Risk of eye damage. Do not look into the beam at close range.
1. If already in configuration mode, go to step 6.
2. If the lamp is connected to the power supply, disconnect it.
3. Connect the red wire to 10-30 V DC via a 5 A fuse.
4. Connect the black wire to ground.
!
