CAUTION
When drilling, take care to avoid any electrical wiring, gas or water
pipes located in or behind the wall.
Safety glasses should be worn anytime a drill is being used.
If unsure what type of wall screw and wall plug to use. Please see
your local hardware store for assistance.
PIC. 4
PIC. 5
ATTACHING COMPRESSOR TO WALL
1. Select a suitable location, not in a walkway.
2. Using the large wall bracket as a template mark and drill two
mounting holes.
3. Using two suitable screws (not supplied) attach the wall bracket
to the wall, Pic. 4.
Note: If unsure of what screws to use please discuss with your
local hardware store.
4. Clip the compressor into place and ensure that compressor is
located fully before allowing to hang, Pic. 5.
Wall Bracket
(Large)
Screws
Large Wall Bracket
Small Wall Compressor Bracket
Compressor
