10 11
policy regarding returns that are beyond the time set for exchanges. (2) Return the product to the manufacturer for repair or
replacement at manufacturer’s option. Proof of purchase may be required by manufacturer.
This warranty does not apply to accessories, bulbs, fuses and batteries; defects resulting from normal wear and tear, accidents;
damages sustained during shipping; alterations; unauthorized use or repair; neglect, misuse, abuse; and failure to follow
instructions for care and maintenance for the product.
This warranty gives you, the original retail purchaser, specific legal rights and you may have other rights which vary from state to
state or province to province. This product is not intended for commercial use.
Please complete the Warranty Activation Card and return within 30 days from purchase of the product to: Baccus Global LLC, 595 S.
Federal Highway, Suite 210, Boca Raton, FL 33432. Baccus Global LLC, toll-free number: (877) 571-2391.
SPECIFICATIONS
BC1509 BC2509 BC4009
Input: 120VAC, 60Hz, 4A 120VAC, 60Hz, 6.5A 120VAC, 60Hz, 9.5A
1100W engine start 1500W engine start
Output: 12VDC, 15A 12VDC, 25A 12VDC, 40A
75A engine start 110A engine start
(5 minutes OFF, 5 seconds ON) (5 minutes OFF, 5 seconds ON)
Imported by
Baccus Global LLC
595 S. Federal Highway, Suite 210
Boca Raton, FL 33432
(877) 571-2391
RD011711
The digital display shows the countdown. The bars on the battery icon will change from empty to solid (bottom to top)
repeatedly and the arrow logos pointing to the “+” and “–” flash.
*The countdown will commence from “8” to “0.
3. When “0 is reached, the “pump engine” icon (
) will begin flashing for two minutes. The vehicle is ready to start.
4. Crank the engine using manufacturer’s guidelines, typically in 3 to 5 second bursts. The function requires a resting/cooling
period between attempts. Wait 4 to 5 minutes before a second attempt at starting the engine, if needed.
Two minutes after the pump engine icon flashes, the charger automatically reverts to charging mode. To stop charging, press the
charge button.
When disconnecting charger, disconnect AC cord, remove clamp from vehicle chassis, and then remove clamp from battery
terminal.
Using the Engine Start Function (BC2509 and BC4009)
1. Set up the battery charger and connect to the battery following steps 1 through 2 in theCharging the Battery section.
2. Press the engine start button. The LCD screen will display the following*:
The digital display shows the countdown. The bars on the battery icon will change from empty to solid (bottom to top)
repeatedly and the arrow logos pointing to the “+” and “–” flash.
*The countdown will commence from “90” to “0”.
Note:
The engine start countdown process can be terminated by pressing the engine start button again.
3. When “0 is reached, a beep will sound and the vehicle is ready to start.
4. Crank the engine using manufacturer’s guidelines, typically in 3 to 5 second bursts.
5. After cranking, the unit will automatically adjust the charging current to 2A for 5 minutes and then revert to charging mode. To
stop charging, press the charge button.
When disconnecting charger, disconnect AC cord, remove clamp from vehicle chassis, and then remove clamp from battery
terminal.
TROUBLESHOOTING
Unit Not Charging
• Check that the charger is properly connected to a live 120 volt AC outlet.
If the battery to be charged has fallen below 2 volts, the battery cannot be recharged with these chargers.
CARE AND MAINTENANCE
Storage
• Store the unit in a clean, dry, cool place when not in use.
• Clean the unit casing and cords (as necessary) with a dry (or slightly damp) cloth. Ensure that unit is completely disconnected
from battery and power source before cleaning.
• To maintain the operating condition and maximize the life of the charger cords, always coil them loosely for storage. Do not wrap
them around the unit or crimp them with a tight band.
ACCESSORIES
Recommended accessories for use with your tool are available from your local dealer. If you need assistance regarding accessories,
please contact manufacturer at (877) 571-2391.
WARNING: The use of any accessory not recommended for use with this appliance could be hazardous.
SERVICE INFORMATION
Whether you need technical advice, repair, or genuine factory replacement parts, contact the manufacturer at (877) 571-2391.
ONE YEAR LIMITED WARRANTY
The manufacturer warrants this product against defects in materials and workmanship for a period of ONE (1) YEAR from the date
of retail purchase by the original end-user purchaser (“Warranty Period”).
If there is a defect and a valid claim is received within the Warranty Period, the defective product can be replaced or repaired in
the following ways: (1) Return the product to the retailer where product was purchased for an exchange (provided that the store
is a participating retailer). Returns to retailer should be made within the time period of the retailer’s return policy for exchanges
only (usually 30 to 90 days after the sale). Proof of purchase may be required. Please check with the retailer for their specific return
BC1509_2509_4009_ManualENSP_011711.indd 10-11 1/17/2011 11:06:50 AM
