33
Instruction Manual
Getting Started
A. Pair a STANLEY BR-Series Cordless Tool to EXPERT, SPECIALIST, or, NETWORK NODE
NOTE: Do not remove the battery pack from the BR-Series cordless tool during this process.
Steps:
1. First turn ON the wireless Radio, choose a power level and save it. Next create “SSID” and “Password” for your wireless
radio of the QBE Controller.
2. Use the controller keypad (EXPERT and SPECIALIST only) or Alpha Toolbox (NETWORK NODE - Chapter 2.13) to navigate to
the WIFI tab under SETUP / COMMUNICATIONS.
3. Press the PAIR button.
4. This will put the STANLEY EXPERT, SPECIALIST, or NETWORK NODE controller in search mode.
5. Bring the BR-Series cordless tool within range of the associated STANLEY controller.
6. With the BR-Series Cordless tool turned off and battery packed installed, press and hold the mutliple function button (MFB).
While holding the MFB, press and release the start trigger switch. The tool will emit a chirp indicating the start of the pair-
ing process. After the chirp, the MFB can be released. This may take up to 15 seconds. The tool will is required to perform
the homing process following pairing.
7. The orange preventative maintenance (PM) light will flash slowly, and the 2 blue lights will slowly alternate flash to indi-
cate it is searching for the STANLEY controller.
8. When the BR-Series cordless tool and the STANLEY controller connect, the tools status lights will flash in sequence.
9. The STANLEY controller will show an “Accept as Spindle” pop up; Select the desired number for the spindle number and
press the OK button.
10. If the tool does not make a connection to the STANLEY controller after 2 minutes, the BR-Series cordless tool will exit pair-
ing mode and the process will need to be started again.
11. The tool will attach itself as a trailing spindle of the STANLEY controller.
12. Press the BACK button. The tool will briefly disconnect from the STANLEY controller and then reconnect.
13. Do not remove the battery pack during this process.
14. Select the spindle tab which corresponds to the BR-Series cordless tool recently connected and program it to run the de-
sired fastening strategy.
2.17 Tool Installation
Connect the STANLEY BR-Series cordless tools to a STANLEY controller and program it for the operation where the tool will be
used. Follow the pairing procedure in chapter 2.16 “Pairing Tool to Controller” on page 32.
2.18 Nose Assembly and Accessories
WARNING
To Avoid Injury:
Use only STANLEY approved components. Unapproved components may break and cause a hazardous condition. Inspect all com-
ponents prior to use to ensure that it contains no damage.
CAUTION
Inspect nose assembly and components prior to use. Missing or damaged items should be replaced before use.
