Stanley Fatmax FMHT77419 - Frequency Specifications; Duty Cycle Specifications; Resistance Specifications; Capacitance Specifications

22
Frequency
Range Resolution Accuracy
9.999Hz 0.001Hz ± (1.0% + 3)
99.99Hz 0.01Hz
± (0.8% + 3)
999.9Hz 0.1Hz
9.999kHz 1Hz
99.99kHz 10kHz
999.9kHz 10kHz not specified
Input Voltage: 1Vrms -20Vrms
Duty Cycle
Range Resolution Accuracy
5% ~ 99% 0.1%
1 Hz ~10kHz: ± (2% + 5)
> 10kHz: not specified
Input Voltage: 3Vp-p ~ 10Vp-p
Overload Protection: 600V DC/AC rms
Resistance
Range Resolution Accuracy
400Ω 0.1Ω ± (1.0% + 5)
4kΩ 0.001kΩ
± (1.0% + 3)
40kΩ 0.01kΩ
400kΩ 0.1kΩ
4MΩ 0.001MΩ
40MΩ 0.01MΩ ± (1.8% + 5)
Capacitance
Range Resolution Accuracy
40nF 0.01nF ± (4%+20)(REL)
400nF 0.1nF ± (3%+5)(REL)
4µF 0.001µF
± (4% + 5)
40µF 0.01µF
100µF 0.1µF ± (8% + 5)
For the ranges ≤ 400nF, use Relative mode (REL) to subtract the stray
capacitance of the test leads and the Meter.
For the range of 100µF, wait about 30 secs for the reading to settle.
