Stanley Fatmax SFMCCS630 User Manual

14
ENGLISH
Operating the Chain Saw (Fig.A, I, K)

WARNING: Read and understand all instructions. Failure
to follow all instructions listed below may result in electric
shock, fire and/or serious personalinjury.
• Guard Against Kickback which can result in severe
injury or death. See General Power Tool Safety
Warnings and General Chainsaw Safety
Warnings, and Causes and Operator Prevention
of Kickback and Kickback Safety Features, to
avoid the risk ofkickback.
• Do not overreach. Do not cut above chest height.
Make sure your footing is firm. Keep feet apart. Divide
your weight evenly on bothfeet.
• Use a firm grip with your left hand on the front
handle
13
and your right hand on the rear
handle
12
so that your body is to the left of the
guidebar.
• Do not hold chain saw by chain brake/front hand
guard
3
. Keep elbow of left arm locked so that left
arm is straight to withstand akickback.

WARNING: Never use a cross‑handed grip (left hand on
the rear handle and right hand on the fronthandle).

WARNING: Never allow any part of your body to be in line
with the guide bar(4 when operating the chainsaw.
• Never operate while in a tree, in any awkward position
or on a ladder or other unstable surface. You may lose
control of saw causing severeinjury.
• Keep the chain saw running at full speed the entire
time you arecutting.
• Allow the saw chain to cut for you. Exert only light
pressure. Do not put pressure on chain saw at end
ofcut.

WARNING: When not in use always have the chain
brake engaged and batteryremoved.
Setting the Chain Brake (Fig.K)
Your chain saw is equipped with a chain braking system which
will stop the chain quickly in case ofkickback.
1. Remove the battery from thetool.
2. To engage the chain brake, push the chain brake/front hand
guard
3
forward until it clicks intoplace.
3. Pull the chain brake/front hand guard
3
towards the front
handle
13
into the “set” position as shown in Fig.K.
Proper hand position requires the left hand on the front
handle
13
, with the right hand on the rear handle
12
.
Proper Hand Position (Fig.F)

WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position asshown.

WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
installing attachments or accessories. An accidental
start‑up can causeinjury.
OPERATION
Instructions for Use

WARNING: Always observe the safety instructions and
applicableregulations.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
Transporting Chain Saw (Fig.A)
• Always remove the battery from the tool and cover the
guide bar
4
with the scabbard
11
when transporting
thesaw.
Saw Chain and Guide Bar Oiling (Fig.J)
Auto Oiling System
This chain saw is equipped with an auto oiling system that
keeps the saw chain and guide bar constantly lubricated.
1. The oil level indicator 
10
 shows the level of the oil in the
chain saw. If the oil level is less than a quarter full, remove
the battery from the chainsaw and refill with the correct
type of oil.
2. Always empty oil tank when finishedcutting.
NOTE: Always use a high-quality, biodegradable bar and chain
oil for proper saw chain and bar lubrication. When pruning
trees, vegetable-based bar and chain oil is recommended, as
mineral-based oils may harm living trees. Never use dirty, used,
or contaminated oil. Doing so may damage the tool.
Filling the Oil Reservoir
1. Flip down locking lever and unscrew counterclockwise
a quarter turn and then remove the oil cap 
16
 . Fill the
reservoir with the recommended bar and chain oil until the
oil level has reached the top of the oil level indicator 
10
 .
2. Refit the oil cap and tighten clockwise a quarter turn. Flip up
locking lever to its lockedposition.
3. Periodically switch the chain saw off and check the oil
level indicator to ensure the bar and chain are being
properlyoiled.
Replacement chain and bar are available from your
nearest authorized servicecenter.
Available bars and chains for SFMCCS630:
• Bar: 30cm service part number N594322
• Chain: 30cm service part number N580237
2. Remove sprocket cover 
6
 as described in Installing the
Guide Bar and Saw Chainsection.
3. Lift the worn saw chain 
5
 out of the groove in the guide
bar 
4
 .
4. Place the new chain in the slot of the guide bar, making sure
the saw teeth are facing the correct direction by matching
the arrow on the chain with the graphic on the sprocket
cover 
6
 shown in Fig.G.
5. Follow instructions for Installing the Guide Bar and
SawChain.
