Stanley FATMAX V60 User Manual

13
ENGLISH
Replacing Spool Assembly (Fig.O, P)
1. Rotate the spool housing
9
until the hole
24
in the
spindle plate aligns with notch
25
in the housing. Insert a
screwdriver through the notch and into the hole, to prevent
the spindle
26
fromturning.
2. Unscrew and remove the spool housing by turning the
spool grip cover
20
clockwise.
NOTE: Do not try to remove the spool housing by turning the
spool head
30
.
3. Remove spindle plate
27
before installing a new housing.
Remove any dirt and grass from the motor housing and
spindleplate.
4. Install spindle plate onto the spindle, so the double D
shaped retaining nut on the spindle sits inside the base of
the spindleplate.
5. Align the spindle plate hole and notch, insert a screwdriver
back into the hole and thread the new spool housing
counterclockwise. Securely tighten the new spool housing
onto thespindle.
Recommended accessories for use with your tool are available
at extra cost from your local dealer or authorized service center.
If you need assistance in locating any accessory, please visit our
website www.stanley.eu/3.
Use STANLEYFATMAX Model No.STZST1169.
Lubrication
Your power tool requires no additionallubrication.
Cleaning

WARNING: Blow dirt and dust out of the
main housing with dry air as often as dirt is seen collecting
in and around the air vents. Wear approved eye protection
and approved dust mask when performing thisprocedure.

WARNING: Never use solvents or other harsh
chemicals for cleaning the non-metallic parts of the
tool. These chemicals may weaken the materials used in
these parts. Use a cloth dampened only with water and
mild soap. Never let any liquid get inside the tool; never
immerse any part of the tool into aliquid.
Optional Accessories

WARNING: Since accessories, other than
those offered by STANLEYFATMAX, have not been tested
with this product, use of such accessories with this tool
could be hazardous. To reduce the risk of injury, only
STANLEYFATMAX recommended accessories should be
used with thisproduct.
Consult your dealer for further information on the
appropriateaccessories.
Protecting the Environment
Separate collection. Products and batteries marked
with this symbol must not be disposed of with normal
householdwaste.
Products and batteries contain materials that can
be recovered or recycled reducing the demand for raw
materials. Please recycle electrical products and batteries
according to local provisions. Further information is available at
www.2helpU.com.
Rechargeable Battery Pack
This long life battery pack must be recharged when it fails to
produce sufficient power on jobs which were easily done before.
At the end of its technical life, discard it with due care for our
environment:
• Run the battery pack down completely, then remove it from
thetool.
• Li-Ion cells are recyclable. Take them to your dealer or a
local recycling station. The collected battery packs will be
recycled or disposed ofproperly.
Guarantee
1 Year Guarantee
All STANLEY FATMAX power tool products include a 1 year
guarantee as standard. In the unlikely event that your powertool
becomes defective due to faulty materials or worksmanship
within 1 year of purchase, STANLEY guarantees to replace or
repair all defective parts free of charge, or – at our discretion –
replace the item free ofcharge.
3 Year Guarantee
Register your STANLEY FATMAX power tool within 4 weeks
of purchase and qualify for an additional 2 year guarantee.
Having registered your power tool, in the unlikely event that
your powertool becomes defective due to faulty materials or
worksmanship, STANLEY guarantees to replace or repair all
defective parts free of charge, or – at our discretion – replace the
item free ofcharge.

Stanley FATMAX V60 Specifications

General

Brand	Stanley
Model	FATMAX V60
Category	Trimmer
Language	English
