20 ► HD45 User Manual
ITEM
NO.
PART
NO. QTY. DESCRIPTION
1 07483 1 HANDLE
11358 1 HANDLE
(HD4511001, HD4531001 ONLY)
2 04371 1 TRIGGER
3 04077 1 VALVE SPOOL, OC
04593 1 VALVE SPOOL, CC
4 20499 1 CHARGING VALVE
5 07492 2 SPIROL PIN, 1/4 O.D.× 1.250 LG
6 04372 2 CAPSCREW
7 04932 2 SIDE ROD
8 04374 2 LOCK NUT
9 04056 1 ROD WIPER
10 01362 1 O-RING
11 00293 1 O-RING
12 04057 1 BUSHING
13 04058 1 SPRING
14 07479 1 ACCUMULATOR DIAPHRAGM
15 05988 1 ACCUMULATOR, VALVE BLOCK ASSY
16 04378 1 PORTING BLOCK
17 04379 2 O-RING
18 04380 1 AUTOMATIC VALVE BODY
19 02900 4 ROLL PIN, 1/8 × 1/2
20 04381 2 BACK-UP RING
21 04571 2 PUSH PIN
22 04382 1 AUTOMATIC VALVE
23 04383 1 FLOW SLEEVE TUBE
24 04605 4 PUSH PIN
25 04384 1 FLOW SLEEVE
26 04954 1 PISTON
27 02022 1 O-RING
28 04386 1 CUP SEAL
29 04780 1 WASHER
30 04934 1 CUP SEAL
31 05243 1 ORIFICE PLUG
32 09612 1 GPM DECAL
33 74770 1 STANLEY DECAL
34 00682 2 CAPSCREW
35 07493 1 CHARGE VALVE CAP
36 11197 2 BACK-UP RING
37 02494 2 HANDLE GRIP
38 01652 2 HOSE ASSY
39 04936 2 CAPSCREW
40 25534 2 WASHER
41 04937 1 MOTOR CONTROL VALVE
42 01211 1 O-RING
ITEM
NO.
PART
NO. QTY. DESCRIPTION
43 04938 1 WASHER
44 01607 1 SET SCREW
45 04939 1 LEVER
46 04940 1 RETAINING RING
47 00783 1 PIPE PLUG
48 03826 2 BEARING
49 04033 1 IDLER GEAR
50 00713 2 DOWEL PIN
51 04942 1 MOTOR PLATE
52 01257 1 O-RING
53 11196 2 QUAD RING
54 04944 1 DRIVE HEX (LAND MODEL)
06678 1 DRIVE HEX (U/W MODEL)
55 04787 1 KEY
56 05976 1 MOTOR CHAMBER
57 05975 1 DRIVE GEAR
58 04947 2 BEARING
59 04948 1 THRUST WASHER
60 04949 1 THRUST BACK-UP WASHER
61 04950 1 GASKET
62 04759 1 SPRING BACK-UP
63 04951 1 DRIVE MOTOR CONTROL BLOCK
(LAND MODEL)
06680 1 DRIVE MOTOR CONTROL BLOCK
(U/W MODEL)
64 16445 1 LATCH
65 07063 8 WAVE SPRING
66 04756 2 LATCH WASHER
67 04761 1 RETAINING RING
68 01749 2 ROLL PIN
69 00114 1 ROLL PIN
70 00018 2 O-RING
71 76649 1 NAME TAG (CE ONLY)
72 66297 1 SOUND POWER DECAL (CE ONLY)
73 11207 1 CIRCUIT TYPE D DECAL (CE ONLY)
74 28322 1 CE DECAL (CE ONLY)
75 28409 1 COMPOSITE DECAL (CE ONLY)
76 01605 2 O-RING
77 07594 1 TRIGGER LOCK
78 07593 1 SPRING
79 00224 1 RETAINER RING
80 03972 1 COUPLER, FEMALE
81 03973 1 COUPLER, MALE
82 30649 1 MOTOR ASSEMBLY
83 30650 1 MOTOR ASSEMBLY (U/W MODEL)
05839 1 SEAL KIT
HD45 PARTS LIST
