Stanley IntelliLaser Pro User Manual

–4–
Indicator Mark
Level & Plumb Vials
Live Wire LED
Backlit LCD
ON Button / Depth
Detection Mode
Selection
ILLUSTRATION 3
Depth Dectection
Mode Indicator
Battery
Door
ILLUSTRATION 1
Battery
Door
ILLUSTRATION 2
Lit When
Live Wire
is
Detected
Laser Plane
ON
Low Battery
Indicator
Indicator Graphic
A B C
ILLUSTRATION 5
ILLUSTRATION 4
A = Wood or metal stud detection up to 1/2”
B = Wood or metal stud detection up to 1”
C = Wood or metal stud detection up to 1-1/2”
Unit is
Calibrating
Calibration
Complete
Ready to Scan
Live wire
Lit When
Live Wire
is
Detected
Laser Plane
ON
Low Battery
Indicator
Indicator Graphic
A B C
ILLUSTRATION 5
ILLUSTRATION 4
A = Wood or metal stud detection up to 1/2”
B = Wood or metal stud detection up to 1”
C = Wood or metal stud detection up to 1-1/2”
Unit is
Calibrating
Calibration
Complete
Ready to Scan
Live wire
114C IM 14Aug06 8/14/06 7:40 PM Page 5

Stanley IntelliLaser Pro Specifications

General

Power Source	Battery
Battery Type	AA
Laser Wavelength	635 nm
Self-Leveling Range	+/- 4 degrees
Self-Leveling	Yes
Warranty	1 year
Accuracy	+/- 1/8 inch at 30 feet
Battery Life	Up to 20 hours
Outdoor Use	Yes, with detector
