Power Button
Retractable
Legs
To hold adhesive
away from the wall
during placement
Sliding
Adhesive
Plate
Allows tilting of unit
±10˚ to level or
plumb the laser
Release Liner
For proper application
of adhesive to unit,
see illustration 8.
Illustration 7
Illustration 6
Release
Button
For Stand-off legs
Allows legs
to extend
+
_
10˚
TILT
Level &
Plumb Vials
Aligned to the
laser plane
Adhesive
Pad w/
Pull Tab
–5–
