MHP3 DIESEL PARTS
MHP3 DIESEL POWER UNIT ENGINE ILLUSTRATION &
PARTS
ITEM P/N QTY DESCRIPTION
1 — 1 FILTER ASSY (INCL W/ ITEM 19)
2 370508 2 CAPSCREW
3 — 2 CAPSCREW (INCL W/ ITEM 19)
4 31241 4 CAPSCREW
5 03031 4 LOCK WASHER
6 40053 1 COOLER MOUNT
7 56670 1 FUEL FILTER BRACKET
8 40078 1 COOLER
9 — — NO ITEM
10 40054 1 COOLER MOUNT
11 — — NO ITEM
12 56637 1 COOLER BRACE
13 08668 10 SHEET METAL SCREW
14 02474 4 CAPSCREW
15 02477 8 WASHER
16 07783 1 BLOWER HOUSING
17 21681 4 SPACER
18 07818 1 KEY
ITEM P/N QTY DESCRIPTION
19 56641 1 ENGINE, RUGGERINI MD191
20 14876 4 CAPSCREW
21 04585 AR WASHER
22 32232 4 CAPSCREW
23 38878 1 SPACER
24 56640 1 BLOWER WHEEL
25 38877 1 BLOWER HUB
26 39057 1 QD BUSHING
27 — 4 CAPSCREW (INCL W/ ITEM 26)
28 21687 1 COUPLING ASSY
29 08669 1 GASKET
30 56691 1 INLET RING
31 08667 5 TAPPING SCREW
32 03906 2 LOCKNUT
33 69747 1 STREET TEE
34 07821 1 90° ELBOW, 1/2" HOSE, 1/2" NPT
35 07822 1 HOSE BARB, 1/2" HOSE, 1/2" NPT
36 59144 1 MUFFLER BRKT. (NOT SHOWN)
