11
ENGLISH
Chuck installation (FIG. G)
Screw the chuck on by hand as far as it will go and insert screw
(left-hand thread). Tighten screw securely. Tighten the chuck
around the shorter end of a 6.35 mm (1/4") or larger hex key
(not supplied) strike the longer end in the clockwise direction
with a wooden mallet, as shown. Tighten the screw once again
by turning in a counterclockwise direction.
Drill Operation
WARNING: To reduce the risk of serious
personal injury, turn tool off and disconnect
tool from power source before making any
adjustments or removing/installing attachments or
accessories.
WARNING: To reduce the risk of
personal injury, ALWAYS ensure
workpiece is anchored or clamped firmly. If drilling
thin material, use a wood “back-up” block to
prevent damage to the material.
Turn the collar to the drill bit symbol for drilling. Select the desired
speed/torque range using the gear shifter to match the speed and
torque to the planned operation.
• Use sharp drill bits only. For WOOD, use twist drill bits,
spade bits, or
hole saws. For METAL, use high-speed steel
(HHS) twist drill bits or hole saws.
• Always apply pressure in a straight line with the bit. Use
enough pressure to keep drill biting, but do not push hard
enough to stall the motor or deflect the bit.
• Hold tool firmly with both hands to control the twisting
action of the drill.
WARNING: The drill may stall if overloaded
causing a sudden twist. Always expect the stall.
Grip the drill firmly with both hands to control the
twisting action and avoid injury.
• IF DRILL STALLS, it is usually because it is
being overloaded or improperly used. RELEASE
TRIGGER IMMEDIATELY, remove drill bit from
work, and determine cause of stalling. DO NOT CLICK
TRIGGER ON AND OFF IN AN ATTEMPT
TO START A STALLED DRILL — THIS CAN
DAMAG
E THE DRILL.
• To minimize stalling or breaking through the material,
reduce pressure on drill and ease the bit through the last
fractional part of the hole.
•
Keep the motor running when pulling the bit back out of a
drilled hole. This will help prevent jamming.
•
With variable speed drills there is no need to center punch
the point to be drilled. Use a slow speed to start the hole
and accelerate by squeezing the trigger harder when the
hole is
deep enough to drill without the bit skipping out.
Operation as a Screwdriver
Select the desired speed/torque range using the dual range
gear shifter on the top of tool to match the speed and torque to
the planned operation.
Insert the desired fastener accessory into the chuck as you
would any drill bit. Make a few practice runs in scrap or unseen
areas to determine the proper position of the clutch collar.
MAXIMUM RECOMMENDED CAPACITIES
Low Range–1 High Range–2
Bits, Metal
Drilling
6.00 mm 3.00 mm
Wood, Flat
Boring
19.00 mm 12.00 mm
Hole Saws 19.00 mm 16.00 mm
Maintenance
Your STANLEY power tool has been designed to operate over a
long period of time with a minimum of maintenance. Continuous
satisfactory operation depends upon proper tool care and regular
cleaning.
WARNING: To reduce the risk
of serious personal injury, place
the forward/reverse button in
the lock-off position or turn tool
off and disconnect battery pack
before making any adjustments or
removing/installing attachments or
accessories. An accidental start-up can
cause injury.
The charger and battery pack are not serviceable. There are no
serviceable parts inside.
Lubrication
Your power tool requires no additional lubrication.
Cleaning
WARNING: Blow dirt and dust out of the
main housing with dry air as often as dirt is seen
collecting in and around the air vents. Wear
approved eye protection and approved dust mask
when performing this procedure.
