Stanley SLL360 - Operation

12
FMHT77137
Set Up
• Place laser tool on a flat, stable surface.
• If using the auto levelling feature move the pendulum /
transport lock to the unlocked position. The laser tool must
then be positioned in its upright position on a surface that
is within the specified compensation range.
• The laser tool can be placed in any orientation and be
functional only when the pendulum / transport lock is in the
locked position.
Mounting on an Accessories
• Position accessory in a place where it will not be easily
disturbed and near the central location of the area to
be measured.
• Set up the accessory as required. Adjust positioning to
be sure accessory base is near horizontal (within laser
tools compensation range).
• Mount the laser tool to the accessory using the
appropriate fastening method to be used with such
accessory / laser tool combination.
CAUTION:
• Do not leave the laser tool unattended on an
accessory without fully tightening the fastening
screw. Failing to do so may lead to the laser tool
falling and sustaining possible damage.
NOTE:
• It is best practice to always support laser tool with
one hand when placing or removing laser tool from an
accessory.
Operation
NOTE:
• See LED Descriptions for indications during operation.
• Before operating the laser tool always be sure to check the
laser tool for accuracy.
• In Manual Mode, Self-Levelling is OFF. The accuracy of the
beam is not guaranteed to be level.
• Laser tool will indicate when it is out of compensation
range. Reference LED Descriptions. Reposition laser tool
to be closer to level.
• When not in use, please be sure to power OFF the laser
tool and place the pendulum lock in the locked position.
Power
• Press to turn laser tool ON.
• To turn laser tool OFF, repeatedly press until the
OFF mode is selected OR press and hold for ≥ 3
seconds to turn laser tool OFF while in any mode.
Mode
• Press repeatedly to cycle through the available
modes.
Self-Levelling / Manual Mode
(See figures
C
and
F
)
• The pendulum lock on the laser tool needs to be
switched to the unlocked position to enable self-
levelling.
• The laser tool can be used with the pendulum lock in the
locked position when it is required to position the laser
tool at various angles to project non-level straight lines
and/or points (where applicable).
Accuracy Check and
Calibration
NOTE:
• The laser tools are sealed and calibrated at the factory to
the accuracies specied.
• It is recommended to perform a calibration check prior to
its rst use and then periodically during future use.
• The laser tool should be checked regularly to ensure its
accuracies, especially for precise layouts.
• When performing the accuracy checks, use as large of an
area / distance as possible. The greater the area / distance,
the easier to measure the accuracy of the laser.
• Transport lock must be in the unlocked position to
allow the laser tool to self-level before checking
the accuracy.
