Stanley SXPG23701 User Manual

2
3
CONTENTS
Section Page
Technical Information 2
Introduction 3
Warranty Statement 3 - 4
General Safety Instructions 5 - 9
Specific Safety Instructions 10
Fuel + Oil 11
Components and Controls 12 - 13
Unpacking and Assembly 14 - 18
Operating Instructions 19 - 27
Maintenance and Storage 28 - 30
Trouble Shooting 30
Service Log 31
Contact Information 32
TECHNICAL INFORMATION
Specifications
Air-Cooled 2-Stroke engine SXPG23701
Displacement 37cc
Max. engine power 1.2kW
Fuel tank capacity 390ml
Oil tank capacity 210ml
Cutting length 330mm
Weight
5.5 kg
Bar Length max. 356mm (14’’)
Chain pitch 3/8”
Chain gauge 0.50”
Max. Speed 10,000 RPM ± 500 RPM
Engine idle speed 3000 RPM ± 200 RPM
Chain Type 14” 3/8 .050
Guide Bar Type 356mm (14”)
Noise May exceed 115db (A)
Spark Plug Torch L7RTC or NGK BPMR7A
SUGGESTED APPLICATIONS
These are some suggested articles which could be used by this
chainsaw:
• Trees
• Branches
• Fire wood
• Clearing fallen branches
• Sculpturing
Please take note of serial number and write here for ease of
reference:
Serial Number:
Date of Purchase:
Place of Purchase:
Receipt Number:
