INSTALLING THE HARNESS
Connect the latch on the shoulder harness to the strap hanger,
Fig 7.
Adjust the strap to a comfortable position, Fig. 8.
WARNING. Do not allow familiarity with this
product to make you careless. Remember that a
careless fraction of a second is sufficient to inflict
serious injury.
WARNING. Always wear eye protection with side
shields marked to comply with ANSI Z87.1, along with
hearing protection. Failure to do so could result in
objects being thrown into your eyes and other possible
serious injuries.
WARNING. Do not use any attachments or
accessories not recommended by the manufacturer
of this product. The use of attachments or accessories
not recommended can result in serious personal injury.
WARNING. Operation of this equipment could
create sparks that can start fires around dry vegetation.
A spark arrestor may be replaced. The operator should
contact local fire agencies for laws or regulations
relating to fire prevention requirements.
ADDING/CHECKING ENGINE OIL
NOTE:
1. Attempting to start the engine before it has been properly
filled with oil will result in equipment failure.
2. Engine oil has a major influence on engine performance
and service life. This unit is shipped without engine oil.
ASSEMBLY
OPERATION
Fig. 7
Fig. 8
3. Always use a good quality 4-stroke engine oil. SAE 30,
SAE 10W-30 or SAE 10W-40 are all acceptable oils to use in
this product. Non-detergent or 2-stroke engine oil will
damage the engine and should not be used.
4. Check oil levels before each use.
TO ADD ENGINE OIL: INITIAL USE
1. Remove the cap from the empty lubricant bottle provided.
2. Pour 60ml 4-stroke engine oil into lubricant bottle with
funnel.
3. Unscrew the oil cap from the engine and remove.
4. Pour 60ml lubricant oil into oil fill hole. Replace and tighten
the oil cap.
